What's in the Package
- 10 ×5″ Multi Lift Sub, NC 50 × NC 38
- 5 ×5″ Lift Sub, 6 5/8 REG × NC 50
- 5 ×5″ Lift Sub, 7 5/8 REG × NC 50
- 3 ×5⅞″ Lift Sub, 7 5/8 REG × MT57
- 2 ×5″ Lift Sub, 6 5/8 REG pin only
- 2 ×6⅝″ Lift Sub, 6 5/8 REG pin only
- 2 ×6⅝″ Lift Sub, 7 5/8 REG × 6 5/8 FH
- 2 ×6⅝″ Lift Sub, 7 5/8 REG × NC 50
- 1 ×5½″ Lift Sub, 5 1/2 FH VAM EIS × NC 50
- 1 ×Lift Sub (for links), 6 5/8 REG pin only
- 1 ×6⅝″ Lift Sub, 6 5/8 REG × 6 5/8 FH VAM EIS
- 1 ×6⅝″ Lift Sub, 6 5/8 REG × 6 5/8 REG
- 1 ×6⅝″ Lift Sub, DC 58 × NC 50
Lift Sub Package
Package of 36 units, sold together
Description
Package of lift subs and multi lift subs in a range of connections — NC 50, NC 38, 6 5/8 and 7 5/8 REG, 6 5/8 FH and MT57 — located in Norway. Every unit has been inspected to NS-2 3rd edition (MPI, visual and dimensional check of the connections) and accepted. Documentation packages and material certificates are on file for many units. Sold as one package. The full unit list is below; inspection reports and documentation are available on request.
Specifications
| Inspection standard | NS-2 3rd edition |
| Inspection scope | MPI, visual and dimensional check of connections |
| Inspection result | All units accepted |
| Material | AISI 4145H (where documented) |
| Manufacture | To NS-1 / API (where documented) |
| Connections | NC 50, NC 38, 6 5/8 REG, 7 5/8 REG, 6 5/8 FH, MT57 |
| Sale | Sold as one package |
Interested in this package?
The units are sold together as one package. Contact us for package pricing, the full inspection reports and documentation, or to arrange an inspection.
Request Package QuotePackage Contents
| Unit | Pin OD | Box OD | ID | Length | Last inspected |
|---|---|---|---|---|---|
| 5″ Multi Lift Sub, NC 50 × NC 38 · 10 units | |||||
| 1 | 6 5/8″ | 8 3/4″ | 3″ | 1,692 mm | Apr 2025 |
| 2 | 6 5/8″ | 8 3/4″ | 3″ | 1,694 mm | Apr 2025 |
| 3 | 6 5/8″ | 8 3/4″ | 3″ | 1,692 mm | Apr 2025 |
| 4 | 6 5/8″ | 8 3/4″ | 3″ | 1,690 mm | Apr 2025 |
| 5 | 6 5/8″ | 8 7/8″ | 3″ | 1,680 mm | Sept 2024 |
| 6 | 6 5/8″ | 8 7/8″ | 3″ | 1,680 mm | Oct 2024 |
| 7 | 6 5/8″ | 8 7/8″ | 3″ | 1,675 mm | Dec 2024 |
| 8 | 6 5/8″ | 8 7/8″ | 3″ | 1,685 mm | Sept 2024 |
| 9 | 6 5/8″ | 8 3/4″ | 3″ | 1,694 mm | Apr 2025 |
| 10 | 6 5/8″ | 8 3/4″ | 3″ | 1,670 mm | Apr 2025 |
| 5″ Lift Sub, 6 5/8 REG × NC 50 · 5 units | |||||
| 11 | 8″ | 6 5/8″ | 3″ | 1,370 mm | Nov 2024 |
| 12 | 8″ | 6 5/8″ | 3″ | 870 mm | Aug 2024 |
| 13 | 8 1/8″ | 7″ | 2 13/16″ | 1,468 mm | Nov 2024 |
| 14 | 8″ | 6 1/2″ | 3″ | 1,460 mm | Mar 2025 |
| 15 | 8″ | 8″ | 3″ | 1,458 mm | Aug 2025 |
| 5″ Lift Sub, 7 5/8 REG × NC 50 · 5 units | |||||
| 16 | 9 1/2″ | 6 5/8″ | 3″ | 1,245 mm | Aug 2024 |
| 17 | 9 1/2″ | 6 5/8″ | 3″ | 1,270 mm | Aug 2024 |
| 18 | 9 1/2″ | 6 5/8″ | 3″ | 1,270 mm | Aug 2024 |
| 19 | 9 1/2″ | 6 5/8″ | 3″ | 1,270 mm | Aug 2024 |
| 20 | 9 1/2″ | 6 5/8″ | 3″ | 1,270 mm | Aug 2024 |
| 5⅞″ Lift Sub, 7 5/8 REG × MT57 · 3 units | |||||
| 21 | 9 1/2″ | 7 1/16″ | 2 13/16″ | 1,660 mm | Mar 2026 |
| 22 | 9 1/2″ | 7 3/32″ | 2 13/16″ | 1,680 mm | Dec 2025 |
| 23 | 9 1/2″ | 7 3/32″ | 2 13/16″ | 1,690 mm | Dec 2025 |
| 5″ Lift Sub, 6 5/8 REG pin only · 2 units | |||||
| 24 | 8″ | — | 2 13/16″ | 756 mm | Feb 2024 |
| 25 | 8″ | — | 2 13/16″ | 857 mm | Feb 2024 |
| 6⅝″ Lift Sub, 6 5/8 REG pin only · 2 units | |||||
| 26 | 8 1/8″ | — | 2 13/16″ | 830 mm | Feb 2024 |
| 27 | 8 1/8″ | — | 2 13/16″ | 800 mm | Feb 2024 |
| 6⅝″ Lift Sub, 7 5/8 REG × 6 5/8 FH · 2 units | |||||
| 28 | 9 1/2″ | 8″ | 3″ | 1,640 mm | Sept 2025 |
| 29 | 9 1/2″ | 8″ | 3″ | — | Sept 2025 |
| 6⅝″ Lift Sub, 7 5/8 REG × NC 50 · 2 units | |||||
| 30 | 9 1/2″ | 8″ | 3″ | 1,230 mm | Feb 2024 |
| 31 | 9 1/2″ | 8″ | 3″ | 1,235 mm | Jan 2024 |
| 5½″ Lift Sub, 5 1/2 FH VAM EIS × NC 50 · 1 unit | |||||
| 32 | 7 1/2″ | 6 3/4″ | 3″ | 1,621 mm | Oct 2024 |
| Lift Sub (for links), 6 5/8 REG pin only · 1 unit | |||||
| 33 | 7″ | — | 6 1/8″ | 820 mm | Jul 2024 |
| 6⅝″ Lift Sub, 6 5/8 REG × 6 5/8 FH VAM EIS · 1 unit | |||||
| 34 | 8″ | 8″ | 3″ | 1,545 mm | Feb 2024 |
| 6⅝″ Lift Sub, 6 5/8 REG × 6 5/8 REG · 1 unit | |||||
| 35 | 8″ | 8″ | 3″ | 854 mm | Feb 2024 |
| 6⅝″ Lift Sub, DC 58 × NC 50 · 1 unit | |||||
| 36 | 8″ | 8″ | 2 1/4″ | 1,305 mm | Feb 2023 |
All units inspected to NS-2 3rd edition and accepted. Full inspection reports and documentation packs are available on request.
